| MOQ: | 1kg |
| Price: | US $60/kg |
| Standard Packaging: | Cylinder/Tank |
| Delivery Period: | 15 days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 20000 Tons/Year |
Nitrogen trifluoride (NF3) is a chemical compound composed of one nitrogen atom bonded to three fluorine atoms. It is a colorless, odorless gas at room temperature and is commonly used in various industrial applications. Here are some key points about nitrogen trifluoride:
Chemical Composition: Nitrogen trifluoride consists of one nitrogen (N) atom bonded to three fluorine (F) atoms. Its chemical formula is NF3.
Production: Nitrogen trifluoride is typically produced through the reaction of ammonia (NH3) with fluorine gas (F2):
NH3 + 3F2 → NF3 + 3HF
This reaction occurs at elevated temperatures in the presence of a catalyst.
Properties: NF3 is a non-flammable, non-toxic gas with a slightly sweet odor at high concentrations. It is stable and does not react with most common materials at room temperature. It has a boiling point of -129 degrees Celsius (-200 degrees Fahrenheit) and can exist as a gas at room temperature and pressure.
Uses: Nitrogen trifluoride has several industrial applications:
Electronics Manufacturing: NF3 is commonly used as a cleaning agent in the electronics industry for removing residues from silicon wafers, chambers, and other electronic components during the manufacturing process.
Plasma Etching: It is used as a plasma etchant in the semiconductor industry to selectively remove materials from the surface of silicon wafers and other substrates.
Solar Panels: NF3 is used in the production of thin-film photovoltaic cells, which are used in solar panels.
Fluorinating Agent: It can be employed as a fluorinating agent in various chemical reactions for introducing fluorine atoms into organic molecules.
Environmental Impact: Nitrogen trifluoride is a potent greenhouse gas with a high global warming potential. It has a long atmospheric lifetime, contributing to its potential impact on climate change. Due to its increasing use in various industries, efforts are being made to monitor and reduce emissions of NF3.
When handling nitrogen trifluoride, appropriate safety measures should be followed, including working in well-ventilated areas and wearing proper protective equipment. Care should also be taken to prevent exposure to high concentrations, as NF3 can displace oxygen and cause asphyxiation in confined spaces.
It's important to handle and use nitrogen trifluoride responsibly, taking into account its potential environmental impact and safety considerations.
Basic Info.
| Molecular Weight | 147.05 | Density | 2.96Kg/m³ |
| Melting Point | -206.79ºC | Boiling Point | -129.0ºC |
| Appearance | Colorless,Odorless | Un No. | 2451 |
| DOT Class | 2.2&5.1 | Valve | Diss640 |
| Cylinder Standard | GB/ISO/DOT | Cylinder Pressure | 15Mpa/20Mpa |
| Transport Package | 47L/440L | Specification | 99.99%,99.996% |
| Trademark | CMC | Origin | China |
| HS Code | 28129011 | Production Capacity | 5000tons/Year |
Production:
Specification:
|
|
