| MOQ: | 1kg |
| Price: | US $ 9.5/kg |
| Standard Packaging: | Cylinder/Tank |
| Delivery Period: | 15 days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 5000 Tons/Year |
Sulfur hexafluoride (SF6) is a colorless, odorless, and non-flammable gas composed of sulfur and fluorine atoms. It is commonly used as an electrical insulator in high-voltage power transmission equipment, such as circuit breakers, switchgear, and transformers. SF6 has excellent electrical insulation properties, allowing it to effectively extinguish electrical arcs and prevent electrical discharge.
Key properties of sulfur hexafluoride include:
Density: Sulfur hexafluoride (SF6) is denser than air, which makes it suitable for use in high-voltage equipment. Its density allows it to effectively extinguish electrical arcs and enhance the cooling of electrical equipment.
Electrical insulation: Sulfur hexafluoride (SF6) has outstanding dielectric strength, making it an excellent insulating gas for high-voltage applications. It enables the construction of compact and reliable electrical equipment.
Chemical stability: Sulfur hexafluoride (SF6) is chemically stable and non-reactive under normal conditions. It does not react with most materials, including metals, which makes it compatible with a wide range of electrical components.
Thermal conductivity: Sulfur hexafluoride (SF6) has relatively low thermal conductivity compared to other gases. This property helps in preventing thermal losses and maintaining the temperature stability of electrical equipment.
Environmental impact: Sulfur hexafluoride (SF6) is a potent greenhouse gas, with a global warming potential (GWP) significantly higher than that of carbon dioxide (CO2). It has a long atmospheric lifetime, which contributes to its potential impact on climate change. Due to its environmental concerns, efforts are being made to reduce SF6 emissions and find alternative insulation gases.
It's important to handle Sulfur hexafluoride (SF6) with care and follow appropriate safety measures when working with this gas, as it can displace oxygen in confined spaces and pose asphyxiation hazards.
| Transport Package: | 40L, 47L, 50L, 500L | Melting Point | -50.8ºC |
| Trademark: | CMC | Boiling Point | -63.8ºC |
| Specification | 99.995%, 99.999% | Production Capacity | 5000tons/Year |
| Cylinder Pressure | 15MPa/20MPa | Valve | Qf-2, Cga590 |
| Appearance | Colorless, Odorless | Density | 6.0886 Kg/M³ |
Specifications
| Specifications | Company Standard |
| SF6 | ≥ 99.995% |
| Air | ≤ 10 ppm |
| CF4 | ≤ 2 ppm |
| C2F6 | ≤ 20 ppm |
| C3F8 | ≤ 5 ppm |
| Low Sulfide | Not Detected |
| H2O | ≤ 1 ppm |
| Acidity as HF | ≤ 0.1 ppm |
| Hydrolysable Fluor ides as HF | ≤ 0.3 ppm |
| Mineral Oil | ≤ 1 ppm |
Detailed Photos
|
|
