| MOQ: | 1kg |
| Price: | US $ 9.5/kg |
| Standard Packaging: | Cylinder |
| Delivery Period: | 15 days |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 5000 Tons/Year |
Sulfur hexafluoride (SF₆) is an inorganic compound composed of one sulfur atom bonded to six fluorine atoms. It is a colorless, odorless, non-flammable, and non-toxic gas. SF₆ has a high density, similar to that of air, and is commonly used as an insulating material in electrical equipment due to its excellent electrical insulation properties.
Here are some key characteristics and applications of sulfur hexafluoride:
Insulating gas: SF₆ is widely used as an insulating gas in high-voltage electrical equipment such as circuit breakers, switches, and transformers. It prevents electrical discharges and insulates the equipment, allowing for efficient and reliable operation.
Dielectric properties: SF₆ has exceptional dielectric strength, meaning it can withstand high electric fields without breaking down. This property makes it suitable for use in high-voltage applications, where it helps to prevent electrical arcing and corona discharges.
Medical applications: Sulfur hexafluoride is used in medical imaging techniques such as ultrasound and MRI (Magnetic Resonance Imaging). In ultrasound, it is used as a contrast agent to enhance the visibility of blood vessels and organs. In MRI, SF₆ is used to fill the sealed cavities of respiratory systems to improve image quality.
Industrial uses: SF₆ finds applications in various industries. It is used as a tracer gas in leak detection systems for enclosed spaces, such as buildings or manufacturing facilities, to identify and locate gas leaks. SF₆ is also used in the production of semiconductors and electronic components.
Environmental impact: Sulfur hexafluoride is a potent greenhouse gas with a high global warming potential (GWP). It has a long atmospheric lifetime, contributing to its impact on climate change. Efforts are being made to reduce its emissions, and alternative gases with lower environmental impact are being explored for use in electrical equipment.
It's important to handle SF₆ with care and follow appropriate safety measures to prevent its release into the atmosphere.
Basic Info
| DOT Class | 2.2 | Un Number | Un 1080 |
| Cylinder Standard | DOT/ISO/GB | Cylinder Pressure | 15MPa/20MPa |
| Valve | Qf-2, Cga590 | Melting Point | -50.8 ºC |
| Appearance | Colorless, Odorless | Boiling Point | -63.8 ºC |
| Density | 6.0886 Kg/M³ | Molecular Weight | 146.05 |
| Transport Package | 40L, 47L, 50L, 500L | Specification | 99.995%, 99.999% |
| Trademark | CMC | Origin | China |
| HS Code | 28129019 | Production Capacity | 5000tons/Year |
Specifications
| Specifications | Company Standard |
| SF6 | ≥ 99.995% |
| Air | ≤ 10 ppm |
| CF4 | ≤ 2 ppm |
| C2F6 | ≤ 20 ppm |
| C3F8 | ≤ 5 ppm |
| Low Sulfide | Not Detected |
| H2O | ≤ 1 ppm |
| Acidity as HF | ≤ 0.1 ppm |
| Hydrolysable Fluor ides as HF | ≤ 0.3 ppm |
| Mineral Oil | ≤ 1 ppm |
Detailed Photos
|
|
